G9KA: High power PCB Relay with ultra-low contact resistance launched

By OEM Update Editorial July 8, 2021 2:02 pm IST

This low-heat generating relay contributes to realisation of decarbonised society by improving energy efficiency through heat generation suppression.

OMRON’s electronic and mechanical component business division’s global launch of its High-Power PCB Relay – G9KA product improves the power generation efficiency of PV generation systems by minimising energy loss caused by the heat generated by power conditioners, power supply equipment, and related equipment used in solar power generation systems. The industry-leading ultra-low contact resistance of 0.2mΩ suppresses the heat generated by the relay and improves the power generation efficiency of solar power generation systems, thereby accelerating renewable energy deployment and contributing to the realisation of a decarbonised society.

One of the factors that can cause the equipment to generate heat is the relays mounted on the PC board inside the equipment. Relays are components used for executing ON/OFF control of the electric current flowing through the equipment when linked with the power system, and for safety shutoff in an emergency. Conventional high-power relays have a high contact resistance value, so energy loss due to heat generation has been an issue.

The G9KA can reduce the temperature rise of the relay about 30% – compared with conventional high-power relays – by lowering the contact resistance to the industry-leading 0.2mΩ. This product helps to reduce the size and weight of equipment by simplifying the heatsink and cooling fan that were installed as a countermeasure against heat generation. In addition, suppressing the heat generated by the relay leads to a reduction in the temperature rise of the PC board, thereby contributing to the longevity of the equipment.

For more info, visit: https://www.omron.com/
